SounDigital 1500.5 GAN (4 x 125 watts + 1000 mono watts) 5 channel super amp.

• In our relentless pursuit of excellence, we take pride in introducing the next major advancement in the world of automotive audio. The most advanced and exclusive amplifier developed is born from our commitment to quality and innovation. We Introduce you to GAN, the redefinition of audio.

• GAN technology is the most modern in terms of transistors, being superior to the MOSFETs used in current day Class D amplifiers. Switching speed and current conduction are far superior in the GAN transistor, which elevates both efficiency and the sound quality characteristics of the amplifier. You will fall in love with your favorite songs all over again.

• GAN is a HEMT (high electronic mobility transistor), which has two main advantages in the world of switching devices. One is that this transistor has much higher capacity of current conduction than a conventional MOSFET, reducing its internal resistance and the quantity of devices needed in higher powered applications. The second is that they also switch extremely fast in comparison to MOSFET. The speed and frequency of the switching directly correlates to the amplifier's THD, frequency range, and SNR, the Achilles heel of Class D technology.

• These advantages have allowed the new GAN amplifiers to be more efficient and smaller than could have been imagined, while delivering an extremely elevated listening experience. The detail and clarity can only be accompanied by what has been explained as an open and airy environment. Our GAN amplifiers will change the way music is experienced.

Audio Detail:

• Enjoy all the nuances music has to offer thanks to the extended frequency response. The GAN amplifiers easily surpass the "traditional" 20kHz of current amplifiers, creating a truly immersive experience.

High Fidelity:

• Audio amplifiers with GAN technology have an extremely low THD (Total Harmonic Distortion), which maximizes music fidelity.

Ultra-Low Noise:

• SounDigital GAN amplifiers deliver outstandingly low noise levels due to the high Signal-to-Noise ratio (SNR). This means you will enjoy exceptionally clear sound.

Channels 1 - 4:

• Power @ 4 Ohms: 4 x 125W RMS
• Power @ 2 Ohms: N/A
• Bridge Power @ 8 Ohms: 2 x 250W RMS
• Operating Voltage: 9V ~ 16V
• Current Draw (Music): 65A
• Current Draw (Max): 130A
• Recommended Fuse (Music): 80A
• Total Efficiency: 80%
• Frequency Response: 6Hz ~ 65.25kHz
• SNR: 105dB
• Crossover LPF: 45 ~ 850Hz
• Crossover HPF: 45 ~ 850Hz

Channel 5:

• Power @ 4 Ohms: 1 x 660W RMS
• Power @ 2 Ohms: 1 x 1000W RMS
• Operating Voltage: 9V ~ 16V
• Current Draw (Music): 65A
• Current Draw (Max): 130A
• Recommended Fuse (Music): 80A
• Total Efficiency: 80%
• Frequency Response: 6Hz ~ 511kHz
• SNR: 105dB
• Subsonic: 8Hz ~ 20Hz
• Crossover LPF: 50 ~ 511Hz
• Bass Boost: 0 ~ 12dB @ 50Hz

Dimensions:

• L x W x H: 30.7cm / 12" x 14.9cm / 5.9" x 5.5cm / 2.1"
• Net Weight: 2.10kg / 4.62lb
• Gross Weight: 3.82kg / 8.42lb
